Plastic Drinking Straw Making Machine

Musa Body Technician — Wed, 19 Nov 2025 09:11:33 +0000

Product Paramenters

Plastic Stick extrusion machine
Name	SJ50 Plastic Stick extrusion machine
Model		SJ50	SJ50/25	SJ50/25/25
Description	1. Main parts are: extruder, cooling water tank, vacuum shaping equipment, air compressor, hauling cutting system, single color, bicolor or tricolor pipes can be realized.
	2. Main screw diameter: 50mm, important parts such as screw and cylinder adopts superior alloy steel with nitrogen treatment, 38CrMoAlA (nitrogen treatment, depth 0.2~0.7mm)
	3. Aspect ratio: 28:1
	4. Diameter of sub-screw:25mm, Aspect ratio: 20:1
	5. Extruding power: 11kw (frequency conversion control)
	6. The die undergoes nitride hardening treatment for a long service time
	7. The water tank and the surface of cutting machine are made of 304 stainless steel
	8. The main extruder’s screw designed to suit plastic material specified. Tube dies head assembly manufactured in tool steel.
	9. All the electrical parts use SCHNEIDER or SIEMENS or Delta
Power Supply	Main screw	380v ,3phase,50hz,7.5kw(VFD)
	Sub-screw	/	0.75kw	0.75×2kw
	Heating	7kw	9.56kw	12kw
	Hauling motor	0.75kw(VFD)
	Cutting motor	0.75kw(VFD)
	Total power	16.5kw	20kw	22.5kw
Temperature Controller		5 sets	8 sets	11 sets
Electric control cabinet		1 set	1 set	1 set
Automatic Counting Device		1 set	1 set	1 set
Way of Hauling		By rubber roller
Way of cutting		Rotatory cutting length range 50-300mm
Cooling water tank	Usually 4.4m, can be adjusted up&down, right &left, forward&backward. Made of superior stainless teel
Option	Vacuum pump (0.75kw)		Air compressor (2kw)
Sticks Sepc	Material	PLA PP PE etc
	Stick Diameter	2mm~13mm can be custiomized for special requirement
	Stick Length	Customizable
	Speed	600~1000pcs/min (product rate : 20kg/h-30kg/h
	Color	Single	Two colors	Three colors
	Straight or spiral	√	√	√
	Cutting End	90°/90°,90°/45°,90°/60°,45°/45°,60°/60
Dimension	LWH	8m1m1.7m	8m1.5m1.7m	8m2m1.7m
Weight		1500kg	1700kg	2000kg

The post Plastic Drinking Straw Making Machine appeared first on Musa Body Machinery.

Manual Chalk Making Machine

Musa Body Technician — Wed, 19 Nov 2025 09:08:11 +0000

Specifications:

1.free of dust 2.great treatment ability 3.wearable- resistant and longevity/durable Durable dustless chalk machine

The DS800-1 series chalk machine is the most advanced manufacturing production equipment of high quality at home. One mould , manual mixing , one worker . One worker can operate 3 sets,package need 1 person

. Model: DS800-1 Capacity: 4000-8000 pcs/ h Mold size: 800 pieces/per mold Chalk size: 10 mm*8 mm* 75 mm Package size: 640*460*350(L*W*H) Weight: about 57kg

Chalk production process
1. Mold evenly brush oil, brush back and forth with a wide brush, brush the new mold should be more oil.
2. The mold plate moving up and down a few times, the screw top and the bottom plate comes into contact.
3. Turn on the water, turn on the water with a movable foot switch pedal to pedal in the end, until the water in the water last.(First mold first feed, add water)
4. Addition, the quantitative good gypsum powder into the mixing bucket.
5. Mixing, stirring for 10-20 seconds to start the motor.
6. Put the pulp, put a good brush oil stirred to die bottom of the barrel, hit the switch to open the pulp slurry was stirred well into the mold until the stream last.
7. Calibrating with a plastic scraper to scrape the pulp mold hole, scrape out the remaining pulp mold mouth gelling.
8. A mold, a new mold die not too late. Chalk can feel a little hard to top 2-5 mm, 1 to 2 minutes over again ejection.

Other Model

Model	Capacity (pcs/h)	Mold Specification (pcs/ mold)	Mold number	Operator
DSQ-400-1	2000-4000	400	one	One
DSQ-800-1	4000-8000	800	one	One
DSQ-800-2	8000-12000	800	two	One
DSQ-800-4	12000-24000	800	four	One
DSQ-800-6	24000-32000	800	six	two
DSQ-800-8	32000-48000	800	eight	three

The post Manual Chalk Making Machine appeared first on Musa Body Machinery.

Paper Bag Making Machine

Musa Body Technician — Wed, 19 Nov 2025 08:58:35 +0000

This machine can use the rolling paper, which is made of primary color paper or printed to produce square bottom paper bag to one time. This machine can produce various of paper bags, with fast speed, high production efficiency, is an ideal equipment for paper bag production.

This machine is composed of rolling paper feed (hydraulic feeding, automatic deviation correction, constant tension), side glue, printing paper electric eye tracking, original paper into roll, fixed length traction cutting, bag bottom indentation opening bottom, bag bottom gluing folding forming and bag output. The whole machine is controlled by the computer central control system, the touch screen display, and the servo motor controls the length of the paper bag.

According to customer needs, two/ four-color printing machine, Paper bag windowing device and paper bag hand holing device or paper handle bar device can be customized.

Model	XKFD220	XKFD280	XKFD330	XKFD450	XKFD450B	XKFD450C	XKFD540
Bag Tube Length（mm）	190-370	270-530	270-530	285-530	420-760	420-760	420-760
Bag Length（mm）	150-320	225-470	225-470	225-470	320-680	320-640	340-680
Bag Width（mm）	80-220	120-280	120-330	220-450	200-450	200-450	250-540
Bottom Width（mm）	50-120	60-160	60-180	80-220	80-240	120-260	120-260
Side Edge Width（mm）	20-30	25-30	25-30	30	30	30	30-40
Bottom Edge Width（mm）	10-20	15-25	15-25	20-30	20-30	20-30	20-30
Paper Thickness（g/㎡）	50-130	60-160	60-160	80-160	80-160	80-160	90-160
Paper Roll Diameter（mm）	ᴓ1300	ᴓ1300	ᴓ1300	ᴓ1300	ᴓ1300	ᴓ1300	ᴓ1300
Paper Roll Width（mm）	280-710	385-910	385-1050	630-1370	590-1410	590-1450	770-1640
Bag Making Speed（pcs/min）	30-200	30-180	30-160	30-150	30-120	30-120	30-120
Power Supply（kw）	10	12	12	12	16.5	16.5	16.5
Machine Weight（kgs）	5500	7000	8000	9000	10000	10000	12000
Machine Dimension（mm）	8000X2980X1800	9700X2980X1900	9800X3050X1900	10200X3150X2200	11265X3400X2200	11265X3400X2200	11250X3400X2160

The post Paper Bag Making Machine appeared first on Musa Body Machinery.

Book Making Machine

Musa Body Technician — Wed, 19 Nov 2025 08:50:26 +0000

Main Features

1. Adopts high techniques such as microcomputer control,electro-optical tracking,gas-liquid interaction,human-machine interface touch screen operation ans ink flexo priting with environmentally-friendly and scientific.
2. Long life belts are easy and quick to fit, adjust, and maintain. It uses the hydraulic pressure control, producing full print uniform lines. Brake operation is automatic thereby saving paper.
3.The electrical apparatus control system used the most advanced Fieldbus Control System and shaftless servo control system.
4. Low price, strong practicability, stable performance.
5. The longitudinal cutters consistently cut the same size without beveling.

Brief introduction of High speed exercise book making machine /notebook paper machine

High Speed Exercise Book Making Machine /notebook Paper Machine
Product		High speed exercise book making machine /notebook paper machine
Reel width		680-1020mm
Maximum diameter of paper reel		1300mm
Printing speed		0-300m/min
Max.EB.Making speed		45times/min
Printing-cutting length		300-670mm
Power		32kw
Cutting length		250-450mm
Counting and collecting		4-50 sheets
operator		1-3 person
Binging size		125-225mm
Machine net weight		17000/17500kg

The post Book Making Machine appeared first on Musa Body Machinery.

Paint Manufacturing Machines

Musa Body Technician — Wed, 19 Nov 2025 08:34:13 +0000

Suitable for dispersing paint, ink, coating, dyestuff, paper pulp, etc. in chemical industry. They are used for wet dispersing and mixing liquid and suspended solid materials, or detergent. Flexible rotation and vacuum or pressurized function are optional for diverse applications.

Stand style and platform style are optional to fit different usage.

Unique Features

1. Safety design with range controlled switch to ensure hydraulic pole lift within safety range.

2. Rotation shaft with dispersing disc are dynamice balanced to ensure stable processing.

3. Hydraulic driving system to enable steady lifting up and down.

4. Dispersing shaft can revolve around the hydraulic pole to multiple locations as designed to save equipment cost. (ref-erring to right above picture)

Parameter

Type/ Parameter	Power (kw)	Speed (rpm)	Lifting height (mm)	Handling capacity (L)
FDH11	11	0-1200	900	500
FDH30	35	0-1200	1200	1000
FDH45	45	0-1200	1400	2000
FDH75	75	0-1200	1600	3000

The post Paint Manufacturing Machines appeared first on Musa Body Machinery.

Nail Making Machines

Musa Body Technician — Wed, 19 Nov 2025 08:26:27 +0000

Our Z series machines are long life service, low noise with super performance. Automatic nail making machine is mainly used for manufacturing steel nails. The machine is also able to manufacture other steel nails with special specifications, such asdouble-cap nail, felt nail, V-nail, corrugated plate nail, U-nail, injecting-nail, gun nail and etc. after little reformation. The manufactured nails can be extensively used in industry, building, repairing and etc.

Product Paramenters

Model	Z94-1C	Z94-2C	Z94-3C	Z94-4C	Z94-5C	Z94-6C	Z94-8C
Nail diameter	0.9-1.6 mm	1.2-2.8 mm	2.0-3.4 mm	3.4-5.0 mm	3.4-5.0 mm	3.4-8.0 mm	3.0-8.0 mm
Nail length	9-25 mm	16-25 mm	40-80 mm	70-110 mm	70-180 mm	70-220 mm	100-330 mm
Speed	450 pcs/min	350 pcs/min	280 pcs/min	220 pcs/min	200 pcs/min	160 pcs/min	60-90 pcs/min
Power	1.5 kw	3 kw	3 kw	4 kw	5.5 kw	7.5 kw	11 kw
Dimension	144010401270 mm	170013001400 mm	200014001400 mm	240016001650 mm	260017001700 mm	330016501750 mm	350018501900 mm
Weight	450 kg	760 kg	1050 kg	2000 kg	2200 kg	4400 kg	5600 kg

The post Nail Making Machines appeared first on Musa Body Machinery.

Liquid Soap Making Machine Shampoo Detergent Mixer

Musa Body Technician — Wed, 19 Nov 2025 08:18:47 +0000

1.High Performance: The 50L to 100L Mixing Tank Homogenizer is capable of efficiently mixing liquids in a wide variety of industries, including cosmetics, detergents, and food and beverage production.

2.Customizable: This homogenizer offers custom design options, including heating methods, stirrer types, control systems, and more, allowing for a tailored solution to meet unique industry needs.

3.Robust Construction: Constructed from premium materials including SUS304, SUS304L, SUS316, and SUS316L steel, this durable tank is designed to withstand constant use and maintain its high-quality performance over time.

4.Environmentally Friendly: Compliance with product safety and quality standards, including RoHS, ISO9001, and ISO14001, ensures product safety and protection of the environment.

5.Professional after-sales service: This product features professional after-sales service from experienced engineers who are available to service machinery overseas, providing peace of mind for customers who may require assistance or support.

The post Liquid Soap Making Machine Shampoo Detergent Mixer appeared first on Musa Body Machinery.

Bar Soap production line Machines

Musa Body Technician — Fri, 03 Oct 2025 11:33:09 +0000

Introduction

This production line is a soap molding production line that uses soap particles as raw materials and has a production capacity of 100-300 kg/hour. After mixing raw materials, grinding, vacuum stripping, and printing, mid to high grade soap with a fatty acid content of 55-70% can be produced. The soap has a compact structure and is not easy to dry and crack.

Application

Suitable for producing soap, hotel soap, shower soap, laundry soap, soap bars, etc.

Features

1. The machine can automatically complete a series of process flows, effectively improving production efficiency.
2. Having a certain degree of automation control system, it can accurately control various process parameters and ensure the stability of product quality.
3. Using soap production lines for production can effectively reduce manual operations and lower labor costs.

Name:Soap Production Line

Voltage:380V/50HZ

Power:17.9KW

Size:11.5*0.8*1.5m

Paramet

Product Photograph

Toilet Paper Jumbo Roll Rewinding Machine

Musa Body Technician — Fri, 03 Oct 2025 11:19:46 +0000

Toilet Paper Making Rewinding Machine

Main feature: 1.Using computer control system, automatically running, simply operating.Frequency control of motor speed, pneumatic control. 2.Setting perforating, rolling, automatic gluing, cutting, sealing in one machine, ensure rolling steady. 3.Automatic deflashing, making the paper no loss when the toll paper moving into the paper cutter, improving production efficiency and production grade. 4.It can produce hollow -core and solid-core toll toilet paper.

Parameter Sheet

Machine type	JYD- 1092
Width of raw material paper	≤1200mm
Base paper diameter	≤1100mm
Base paper paper core diameter	Φ15-76.2mm
Programmable controller	PLC
Production speed	150-200 m/min.
Machine power	5.5KW
Voltage	380V,50Hz
Diameter of finished products	60-150mm(tightness can be adjusted)
Perforating distance	100-150mm (it can be adjusted)
Holder quantity	1pc
Jumbo roll layer	1-3 ply
Overall size	5.5×2.1×1.5m (L×W×H)
Weight	2.5T

The post Toilet Paper Jumbo Roll Rewinding Machine appeared first on Musa Body Machinery.
